SolidWorks Electrical Training
The goal of this course is to teach you how to use SolidWorks Electrical to optimize your drawings and designs for manufacturability so you can maximize quality, avoid rework and decrease time to market. This course is focused on 2D Schematic Design.
Course Key Learnings:
In the SOLIDWORKS Electrical Basic Training you will learn how to use the software to increase the manufacturability of your 2D designs for electrical diagrams. This helps you to efficiently create electrical systems for your products that can also be put into production immediately.
Course Content:
Module1- PROJECT TEMPLATES
- SOLIDWORKS Electrical
- What are Projects?
- Project Templates
- Project Configurations
- How is a Project Structured?
- Exercise l: Creating a Template
Module2- MODIFYING PROJECT TEMPLATES
- What are Environments?
- Stages in the Process
- Draw Multiple Wires
- Exercise 2: Modifying a Template
Module3-DRAWING TYPES
- What are Drawing Types?
- Existing and Archived Projects
- Line Diagram Symbols
- Schematic Symbols
- Adding Cables
- Symbols Panel and Properties
- Exercise 3: Drawing Types
Module4 SYMBOLS AND COMPONENTS
- What is a component?
- Component Symbol Identification
- Symbol Component Association
- Exercise 4: Symbols and Components
Module5-MANUFACTURERS PARTS
- What are Manufacturers Parts?
- Finding Manufacturer Parts
- Electrical Assemblies
- Exercise 5: Manufacturers Parts
Module6: WIRES AND EQUIPOTENTIALS
- Equipotentials and Wires
- Wire Style Manager
- Replacing Wires
- Wire Numbering Results
- Using Nodal Indicators
- Exercise 6: Wires and Equipotentials
Module7-CABLING
- What is Cabling?
- Detailed Cabling
- Terminal Strip
- Pin to Pin Connections
- Adding Terminals to the Strip
Module8:8SYMBOL CREATION
- Symbols and Standard
- Circuits, Terminals, Types
- Multiple Attribute
- Splitting Attribute Data
PREREQUISITES
Basic knowledge of SOLIDWORKS. Experience with the Windows Operating System.
Who’s this Course for?
Engineers
Designers, and technicians who want to learn how to create electrical schematics, wiring diagrams, and documentation using SOLIDWORKS Electrical
International fee: 300USD
